UFK MultiCut 25/2 ME (EX)

Item number: MULTICUT 25/2 ME: JP50356 · MULTICUT 25/2 ME EX: JP50355

MultiCut submersible pumps from Pentair Jung Pumpen

Submersible pumps with the MultiCut cutting system are used stationary in pressure drainage systems for the drainage of residential areas or individual houses. They are suitable for the discharge of domestic wastewater with common contaminants (as defined in DIN 1986-3).

Depending on the potentially additional cutting system present, the pressure pipe can be used from DN 32 (without cutting system min. DN 80).

The external MultiCut cutting system ensures maximum operational reliability and excellent discharge characteristics. The system is equipped with a cutting plate made of hardened stainless steel (RVS) and a triangular knife. This combination reduces coarse contaminants in the wastewater with more than 200,000 cuts per minute before they can enter the pump's hydraulic components.

Solid matter that cannot be discharged (too hard/large) is separated by the cutting rotor already outside the pump. Specially arranged grooves on the cutting plate ensure that the MultiCut system constantly cleans itself, which provides additional operational reliability and safety.

Advantages and disadvantages:

+ High reliability due to improved cutting technology
+ Adjustable cutting mechanism
+ Oil level in oil reservoir easy to check
+ Explosion-proof design
+ Built-in motor protection
- Cannot cut everything; cutting rotor prevents these parts from being pumped
