Pros and cons:
+ Serious head: up to 16.5 meters — suitable for deep basements and long pressure lines
+ Choice of cutter pump (stainless steel cutter) or TP30 vortex pump with free passage
+ Cast iron pump housing and electropneumatic control box
+ Operates on 230 V with plug
- Large size (32-40 kg)
Powerful wastewater lifting station for heavier duty tasks:
Where small toilet transfer units stop, the HOMA Sanipower begins: a compact wastewater lifting station with a cast iron pump that achieves a head of 16.5 meters or 36 m³/hour. This allows you to overcome a deep basement or a long pipe run — situations where a small transfer unit simply lacks the pressure.
The standard Sanipower has a multi-channel impeller with a pre-positioned stainless steel cutting mechanism, ideal for faecal-containing wastewater through a thin pressure line. The TP30V version has a vortex impeller with a large free passage — the choice for wastewater with coarser solid particles. Both are supplied with an electropneumatic control box and operate on a standard power socket.
Scope of supply:
Reservoir with pump, electropneumatic control box, 2 m cable and plug.
Technical specifications:
| Head (Hmax): | Sanipower: 16.5 m / TP30V version: 11.0 m |
| Flow rate (Qmax): | Sanipower: 21.0 m³/hour / TP30V version: 36.2 m³/hour |
| Power (P2): | 1.0 - 1.2 kW |
| Voltage: | 230 Volt / 1 phase |
| Discharge connection: | 2" ext. |
| Inlets: | DN 50, DN 100 |
| Article numbers: | 9803512H / 9803508H |
Downloads:
Datasheet and manual available upon request via our customer service.
Non-binding advice?
Are you unsure whether to choose the cutter or vortex version, or about the required head? Feel free to contact our customer service — we'd be happy to calculate it for you.
